CNC diamond wire saw machine quarry stone block cutting profiling machine
1) granite quarry diamond wire saw machine has an independent guide rail on each of the four columns. The flywheel elevates and lower along these guide rails. The flywheel works stable, which improve the service life of the diamond wire saw. Flywheel tension has stable, constant stretch mode to enhance cutting accuracy.
2) CNC system makes the man-machine interface easy and flexible. The liner cutting speed can be adjusted according to different cutting requirements.
3) Quarry diamond wire saw machine is an automatic contouring machine, designed for carrying out complex architectural shapes . such as profile ,column slab ,Roman column and words on granite ,marble and every kind of natural stone .
4) In ordering to reducing the diamond wear and tear, quarry diamond wire saw machine equip two big flywheel, one side flywheel installed with hydraulic pressure tense implement, it controls the wire rope tension or guide, at the same time estimate and maintain wire rope pressure. Another driving wheel installed with main motor, the motor equip with transducer, it can control the speed of wire rope between 0-40m/s, the machine can use in all different kind of stone material.
| CNC diamond wire saw machine quarry stone block cutting profiling machine | ||||
| Type | unit | GHSJ-2000 | GHSJ-2500 | GHSJ–3000 |
| Beaded rope diameter | mm | Φ8.8–Φ10.8 | Φ8.8–Φ10.8 | Φ8.8–Φ10.8 |
| Beaded string length | mm | 14200 | 15700 | 17200 |
| Max.working diamensions(L×H×W) | mm | 2000×3000×1500 | 2500×3000×1500 | 3000×3000×1500 |
| Table size(L×W) | mm | 2500×1300 | 2500×1300 | 2500×1300 |
| Main motor power | kw | 11 | 11 | 11 |
| Voltage | V | 380 | 380 | 380 |
| Water consumption | m³/h | 4 | 4 | 4 |
| Trolley dimension(L×H×W) | mm | 6800*6300*3800 | 7800*6300*3800 | 8800*6300*3800 |
| Total weight | kg | 5500 | 5750 | 6000 |
